MX320CD05-G1KD is a 32 inch LCD display with a resolution of 1920x1080 pixels and an LVDS 51PIN interface. This 32 inch LCD Display boasts a brightness of 1000 nits, making it suitable for outdoor visibility. The 32 inch display is designed with an 8-bit 2-port LVDS interface and is intended for applications such as LCD TVs, PCTVs, and commercial displays, where high brightness, a super-wide viewing angle, high color gamut, high color depth, and fast response time are crucial. The outdoor visibility feature indicates the 32 inch LCD Module‘s capability to deliver clear images even in outdoor environments.
Product Structure
Product Structure
LCD Module PIN Function (LVDS 51 PIN)
| PIN No. | Symbol | Description |
| 1~6 | NC | No Connection |
| 7 | LVDS Select | ‘H‘=JEIDA, ‘L‘ or NC=VESA |
| 8~10 | NC | No Connection |
| 11 | GND | Ground |
| 12 | R1AN | FIRST LVDS Receiver Signal (A-) |
| 13 | R1AP | FIRST LVDS Receiver Signal (A+) |
| 14 | R1BN | FIRST LVDS Receiver Signal (B-) |
| 15 | R1BP | FIRST LVDS Receiver Signal (B+) |
| 16 | R1CN | FIRST LVDS Receiver Signal (C-) |
| 17 | R1CP | FIRST LVDS Receiver Signal (C+) |
| 18 | GND | Ground |
| 19 | R1CLKN | FIRST LVDS Receiver Clock Signal (-) |
| 20 | R1CLKP | FIRST LVDS Receiver Clock Signal (+) |
| 21 | GND | Ground |
| 22 | R1DN | FIRST LVDS Receiver Signal (D-) |
| 23 | R1DP | FIRST LVDS Receiver Signal (D+) |
| 24~25 | NC | No connection |
| 26 | NC or GND | No Connection or Ground |
| 27 | NC | No connection |
| 28 | R2AN | SECOND LVDS Receiver Signal (A-) |
| 29 | R2AP | SECOND LVDS Receiver Signal (A+) |
| 30 | R2BN | SECOND LVDS Receiver Signal (B-) |
| 31 | R2BP | SECOND LVDS Receiver Signal (B+) |
| 32 | R2CN | SECOND LVDS Receiver Signal (C-) |
| 33 | R2CP | SECOND LVDS Receiver Signal (C+) |
| 34 | GND | Ground |
| 35 | R2CLKN | SECOND LVDS Receiver Clock Signal (-) |
| 36 | R2CLKP | SECOND LVDS Receiver Cloc kSignal (+) |
| 37 | GND | Ground |
| 38 | R2DN | SECOND LVDS Receiver Signal (D-) |
| 39 | R2DP | SECOND LVDS Receiver Signal (D+) |
| 40~41 | NC | No connection |
| 42~43 | NC or GND | No Connection or Ground |
| 44~46 | GND | Ground |
| 47 | NC | No connection |
| 48~51 | VLCD | Power Supply +12.0V |
