: 8.0" ~ 10.1" IPS TFT LCD

This section primarily focuses on IPS TFT LCDs ranging from 8.0 inches to 10.1 inches. All IPS TFT LCDs are categorized under this section. Our flagship product in this category is the 10.1-inch IPS TFT LCD, which offers pixel resolutions including 1024x600, 1280x800, and 1920x1200, and supports various interfaces such as RGB, LVDS, and MIPI. If you require information on additional sizes or other types of TFT LCDs, please don‘t hesitate to contact our professional sales team for further assistance.

SEND INQUIRY

Size	Resolution	Model No.	Type	PIN	Interface	Brightness	Technology	Viewing Angle(T/B/L/R)	O.T	L.T	Outline Dimension	Active Area
8.0"	800x1280	MX-U80HM31-IP07	Portrait	31pin	MIPI	250 nits	IPS	80/80/80/80	-10~60 °C	20K Hr.	114.60184.102.60	107.64*172.22
9.0"	1024x600	MX-B90HR50-IS02	Landscape	50pin	RGB	450 nits	IPS	80/80/80/80	-20~70 °C	30K Hr.	210.70126.405.00	196.61*114.15
9.0"	1024x600	MX-B90HL60-IS07	Landscape	60pin	LVDS	500 nits	IPS	80/80/80/80	-20~70 °C	30K Hr.	210.70126.405.00	196.61*114.15
10.1"	1024x600	MX-B10HR50-IS23	Landscape	50pin	RGB	600 nits	IPS	85/85/85/85	-20~70 °C	50K Hr.	238.00143.005.20	222.72*125.28
10.1"	1024x600	MX-B101NL40-IS05	Landscape	40pin	LVDS	400 nits	IPS	85/85/85/85	-20~70 °C	50K Hr.	235.00143.003.50	222.72*125.28
10.1"	1280x800	MX-B101FL40-IM21	Landscape	40pin	LVDS	350 nits	IPS	80/80/80/80	-20~70 °C	30K Hr.	228.20148.952.60	216.96*135.60
10.1"	800x1280	MX-A101FL20-IP37	Portrait	20pin	LVDS	300 nits	IPS	80/80/80/80	-10~50 °C	20K Hr.	143.00228.602.60	135.36*216.58
10.1"	800x1280	MX-A101FM40-IX15	Portrait	40pin	MIPI	300 nits	IPS	80/80/80/80	-10~50 °C	30K Hr.	143.00228.602.50	135.36*216.58
10.1"	1920x1200	MX-B101FL45-IM22	Landscape	45pin	LVDS	300 nits	IPS	80/80/80/80	-20~70 °C	30K Hr.	228.16148.912.55	216.81*135.50
10.1"	1200x1920	MX-H101FM40-IP31	Portrait	40pin	MIPI	230 nits	IPS	80/80/80/80	-10~60 °C	10K Hr.	143.00228.602.45	135.36*216.58

8.0" ~ 10.1" IPS TFT LCD
