: 10.4" ~ 21.5" Wide Temperature TFT Display

This section primarily features Wide Temperature TFT displays ranging from 10.4 inches to 21.5 inches. Available sizes include 10.4 inches, 12.1 inches, 15.6 inches, 19 inches, and 21.5 inches, with operating temperature ranges of -20°C to 85°C, -30°C to 80°C, and -30°C to 85°C. Wide Temperature TFT displays are generally designed for use in demanding environments and find applications in industries such as industrial control, maritime, aviation, agriculture, and more. If you wish to inquire about additional sizes or other types of TFT displays, please do not hesitate to contact our dedicated sales team for further information.

SEND INQUIRY

Size	Resolution	Model No.	Type	PIN	Interface	Brightness	Technology	Viewing Angle(T/B/L/R)	O.T	L.T	Outline Dimension	Active Area
10.4"	1024x768	MX-C104HL30-ID071K	Landscape	30pin	LVDS	1100 nits	IPS	80/80/80/80	-30~80 ℃	50K Hr.	227.00175.809.20	210.43*157.82
12.1"	800x600	MX-121SN-01-V403	Landscape	20pin	LVDS	1200 nits	TN	65/75/80/80	-30~85 °C	50K Hr.	279.00209.009.00	246.00*184.50
12.1"	1024x768	MX-H121HL20-IW01	Landscape	20pin	LVDS	600 nits	IPS	85/85/85/85	-30~80 °C	30K Hr.	260.50204.008.60	245.76*184.32
12.1"	1280x800	MX-I121FL30-IY03	Landscape	30pin	LVDS	600 nits	IPS	88/88/88/88	-30~80 °C	50K Hr.	278.00184.0010.00	261.12*163.20
15.6"	1920x1080	MX-U156FL30-IC08	Landscape	30pin	LVDS	500 nits	IPS	85/85/85/85	-30~85 °C	50K Hr.	363.80215.9011.90	344.16*193.59
19.0"	1280x1024	G190ETN01.4-G1KD	Landscape	30pin	LVDS	1000 nits	TN	80/80/85/85	-30~85 °C	50K Hr.	396.00324.0012.88	376.32*301.06
21.5"	1920x1080	MX-215FL30BFH-N07	Landscape	30pin	LVDS	1000 nits	IPS	89/89/89/89	-20~85 ℃	30K Hr.	495.60292.2010.70	476.64*268.11

10.4" ~ 21.5" Wide Temperature TFT Display
