: 5.0" ~ 7.0" IPS TFT LCD

This section primarily showcases IPS TFT LCDs ranging from 5 inches to 7 inches. All IPS TFT LCDs are categorized under this section, with 5-inch and 7-inch IPS TFT LCDs being our flagship products. If you wish to inquire about additional sizes or other types of TFT LCDs, please do not hesitate to reach out to our dedicated sales team for further information.

SEND INQUIRY

Size	Resolution	Model No.	Type	PIN	Interface	Brightness	Technology	Viewing Angle(T/B/L/R)	O.T	L.T	Outline Dimension	Active Area
5.0"	800x480	MX-B50HR40-TIS06	Landscape	40pin	RGB	500 nits	IPS	80/80/80/80	-20~70 °C	50K Hr.	120.7075.903.05	108.00*64.80
5.0"	720x1280	MX-I50HM40-IL04	Portrait	40pin	MIPI	450 nits	IPS	80/80/80/80	-20~70 °C	50K Hr.	66.40120.052.35	62.10*110.40
5.5"	720x1280	HCT546017HDA	Portrait	25pin	MIPI	350 nits	IPS	80/80/80/80	-10~60 °C	30K Hr.	71.00129.661.63	68.04*120.96
7.0"	800x480	MX-070NR50KFS-N57	Landscape	50pin	RGB	200 nits	IPS	85/85/85/85	-20~70 °C	50K Hr.	164.8699.963.50	153.84*85.63
7.0"	800x480	MX-U70NT40-IG48(V02)	Landscape	40pin	RGB	350 nits	IPS	80/80/80/80	-20~70 °C	50K Hr.	165.00104.095.30	152.40*91.44
7.0"	1024x600	MX-B70HR50-IX19	Landscape	50pin	RGB	280 nits	IPS	85/85/85/85	-20~70 °C	50K Hr.	164.0097.002.60	154.21*85.92
7.0"	1024x600	MX-B70HL40-IX20	Landscape	40pin	LVDS	350 nits	IPS	85/85/85/85	-20~70 °C	50K Hr.	165.00100.003.50	154.21*85.92
7.0"	1024x600	MX-B70HM30I-S03	Landscape	30pin	MIPI	500 nits	IPS	85/85/85/85	-20~70 °C	50K Hr.	165.00100.003.50	154.21*85.92
7.0"	1024x600	MX-B70HM30-IX21	Landscape	30pin	MIPI	500 nits	IPS	85/85/85/85	-20~70 °C	50K Hr.	164.0097.002.60	154.21*85.92
7.0"	800x1280	MX-I70FM31-ILX40	Portrait	31pin	MIPI	250 nits	IPS	80/80/80/80	-10~60 °C	20K Hr.	99.76161.602.60	94.20*150.72
