: 12.1" ~ 27" Industrial LCD Module

This section primarily highlights larger-sized Industrial LCD Modules, including commonly used sizes in industrial applications such as 12.1 inches, 15 inches, 15.6 inches, 17 inches, 19 inches, 21.5 inches, and 27 inches. Both TN and IPS types are available, with most modules utilizing an LVDS interface. If you require information on additional sizes, please don‘t hesitate to reach out to our professional sales team.

SEND INQUIRY

Size	Resolution	Model No.	Type	PIN	Interface	Brightness	Technology	Viewing Angle(T/B/L/R)	O.T	L.T	Outline Dimension	Active Area
12.1"	800x600	MX-121SN-01-V403	Landscape	20pin	LVDS	1200 nits	TN	65/75/80/80	-30~85℃	50K Hr.	279.00209.009.00	246.00*184.50
12.1"	1024x768	MX-H121HL20-IW011K	Landscape	20pin	LVDS	1000 nits	IPS	85/85/85/85	-30~80 °C	30K Hr.	260.50204.004.50	245.76*184.32
12.1"	1280x800	MX-121ICE-L02-H	Landscape	30pin	LVDS	1000 nits	IPS	88/88/88/88	-20~70 °C	50K Hr.	278.00184.0010.00	261.12*163.20
12.1"	1280x800	MX-B121FL20-IS81K	Landscape	20pin	LVDS	1000 nits	IPS	85/85/85/85	-20~70 °C	50K Hr.	277.70180.608.70	261.12*163.20
15.0"	1024x768	MX-B150X0M-N101K	Landscape	20pin	LVDS	1000 nits	IPS	89/89/89/89	-20~70 °C	50K Hr.	326.50253.509.70	304.13*228.10
15.6"	1920x1200	MX-H156FL40-IH01	Landscape	40pin	LVDS	250 nits	IPS	89/89/89/89	0~50 °C	15K Hr.	351.86206.336.31	344.16*193.60
17"	1280x1024	MX-B170E0M-N10	Landscape	30pin	LVDS	250 nits	IPS	89/89/89/89	0~50 ℃	30K Hr.	358.50296.507.70	337.92*270.34
19.0"	1280x1024	MX190E0M-N11	Landscape	30pin	LVDS	250 nits	IPS	89/89/89/89	0~50 ℃	30K Hr.	396.00324.009.90	374.78*299.83
19.0"	1280x1024	G190ETN01.4-G1KD	Landscape	30pin	LVDS	1000 nits	TN	80/80/85/85	-30~85 °C	50K Hr.	396.00324.0012.88	376.32*301.06
21.5"	1920x1080	MX-215FL30BFH-N07	Landscape	30pin	LVDS	1000 nits	IPS	89/89/89/89	-20~85 ℃	30K Hr.	495.60292.2010.70	476.64*268.11
27"	1920x1080	MV270FHM-N60	Landscape	30pin	LVDS	250 nits	IPS	89/89/89/89	0~50 ℃	30K Hr.	611.50355.8013.20	597.89*336.31
