MAXEN has launched a new 15.6 inch LCD touch screen, part number MX-156FE30AFM-N17-BEE, designed for industrial HMI systems, embedded terminals, equipment control panels, and professional interactive applications.
This integrated display assembly combines a 1920x1080 Full HD IPS LCD, 600 nits brightness, and a projected capacitive touch screen. The LCD uses a 30-pin eDP interface, while the PCAP touch panel communicates through USB using the ILI2511 touch controller.
With a large display area, clear Full HD image performance, and integrated touch functionality, the module provides a practical display solution for equipment requiring both detailed visual presentation and intuitive touch operation.
Main Features:
The 1920x1080 resolution provides sufficient display space for operating menus, system information, control data, and graphical user interfaces.
Combined with IPS technology, the 15.6 inch Full HD IPS LCD touch screen maintains consistent image quality from different viewing directions, making it suitable for operator panels and embedded terminals installed at different viewing positions.
The 600 nits brightness also supports clear visual presentation in industrial facilities, equipment rooms, and commercial indoor environments with relatively strong ambient lighting.
The projected capacitive touch panel provides responsive touch interaction for equipment control, system settings, parameter adjustment, and interface navigation.
The LCD and touch functions use separate connections:
This integrated LCD touch assembly can help simplify display and touch integration during equipment development.
The 30-pin eDP interface is designed for compatible embedded computers, industrial mainboards, and control platforms with eDP display output.
eDP and LVDS use different signal architectures and are not directly interchangeable. The interface type should therefore be selected according to the system mainboard.
Before integration, the interface pin definition, panel voltage, display timing, cable structure, and mainboard compatibility should be confirmed.
For projects using LVDS output, MAXEN can also evaluate suitable 15.6 inch LVDS display solutions.
The 15.6 inch Full HD IPS LCD touch screen can be used in applications such as:
To support system integration and product evaluation, MAXEN can also provide compatible accessories according to different project requirements.
Available accessories may include:
MAXEN can provide customized display and touch solutions according to different project requirements, including:
The 15.6 inch LCD touch screen combines Full HD resolution, IPS display technology, 600 nits brightness, eDP connectivity, and USB capacitive touch in one integrated display assembly.
For specifications, samples, or customized display requirements, please contact: sales@maxen-lcddisplay.com
The 15.6 inch LCD panel uses a 30-pin eDP interface, while the projected capacitive touch panel communicates through USB using the ILI2511 touch controller.
The eDP connection is used for display signals, and the USB connection is used for touch data.
No. eDP and LVDS use different signal architectures and are not directly interchangeable.
Even when two displays have the same size and resolution, the interface type, pin definition, operating voltage, display timing, connector position, cable structure, and mainboard compatibility should be checked before replacement.
For systems using LVDS output, a compatible LVDS display model should be selected.
No. The same connector pin count does not guarantee direct compatibility.
The interface pin definition, eDP lane configuration, panel voltage, display timing, cable definition, connector position, and mainboard support should be confirmed before integration. mount.
