2.4 inch ~ 4.3 inch IPS TFT LCD-MAXEN - TFT LCD Display Manufacturer, LCD Panel Factory, Touch Screen Supplier

: 2.4" ~ 4.3" IPS TFT LCD

This section primarily features IPS TFT LCDs ranging from 2.4 inches to 4.3 inches. All IPS TFT LCDs are listed under this category. If you require information on additional sizes or other types of TFT LCDs, please feel free to contact our professional sales team for further assistance.

SEND INQUIRY

Size	Resolution	Model No.	Type	PIN	Interface	Brightness	Technology	Viewing Angle(T/B/L/R)	O.T	L.T	Outline Dimension	Active Area
1.69"	240x280	MX-0169NS12EFS-N03	Portrait	12pin	4 wire SPI	400 nits	IPS	/	-20~70 °C	30K Hr.	30.0737.431.60	27.97*32.63
2.4"	240x320	MX-T240MHQS-28	Portrait	30pin	MCU	350 nits	IPS	80/80/80/80	-20~70 °C	50K Hr.	42.7259.462.02	36.72*48.96
2.8"	240x320	MX-028NS33BFS-N06	Portrait	33pin	4 wire SPI	300 nits	IPS	80/80/80/80	-20~70 °C	50K Hr.	50.0069.202.25	43.20*57.60
2.8"	240x320	MX-H28NS40I-WT03(V02)	Portrait	40pin	SPI+RGB	300 nits	IPS	80/80/80/80	-20~70 °C	50K Hr.	50.5069.702.10	43.20*57.60
3.0"	360x640	MX-30HR40-IL01	Portrait	40pin	RGB	500 nits	IPS	80/80/80/80	-20~70 °C	50K Hr.	42.7074.702.20	36.72*65.28
3.5"	320x240	HCT-I035T54-32006L02T	Landscape	54pin	RGB+SPI	550 nits	IPS	80/80/80/80	-30~85 °C	50K Hr	76.9063.903.20	70.08*52.56
4.0"	720x720	MX-B40FM30-IT02	Square	30pin	MIPI	350 nits	IPS	80/80/80/80	-10~60 °C	30K Hr.	83.7083.703.06	71.93*71.93
4.3"	800x480	MX-B43HR-40IS13	Landscape	40pin	RGB	500 nits	IPS	80/80/80/80	-20~70 °C	30K Hr.	105.4267.072.90	95.04*53.86
4.3"	480x800	MX-N43HR42-IT30	Portrait	42pin	MIPI+RGB+SPI	350 nits	IPS	80/80/80/80	-20~70 °C	50K Hr.	62.40105.402.15	56.16*93.60

2.4" ~ 4.3" IPS TFT LCD
