12,1" ~ 27" Industrie-LCD-Modul


In diesem Abschnitt werden hauptsächlich größere industrielle LCD-Module hervorgehoben, einschließlich häufig verwendeter Größen in industriellen Anwendungen wie 12,1 Zoll, 15 Zoll, 15,6 Zoll, 17 Zoll, 19 Zoll, 21,5 Zoll, 27 Zoll und 32 Zoll. Es stehen sowohl TN- als auch IPS-Typen zur Verfügung, wobei die meisten Module eine LVDS-Schnittstelle nutzen. Wenn Sie Informationen zu weiteren Größen benötigen, wenden Sie sich bitte an unser professionelles Verkaufsteam.

ANFRAGE SENDEN
Produkt
Size Resolution Image Model No. Type PIN Interface Brightness Technology Viewing Angle(T/B/L/R) O.T L.T Outline Dimension Active Area
12.1" 800x600 12,1 Zoll 800x600 Industrie-LCD-Panel MX-121SN-01-V403 Landscape 20pin LVDS 1200 nits TN 65/75/80/80 -30~85℃ 50K Hr. 279.00*209.00*9.00 246.00*184.50
12.1" 1024x768 12,1 Zoll 1024x768 Industrie-LCD-Modul MX-H121HL20-IW011K Landscape 20pin LVDS 1000 nits IPS 85/85/85/85 -30~80 °C 30K Hr. 260.50*204.00*4.50 245.76*184.32
12.1" 1280x800 12,1 Zoll 1280x800 Industrie-LCD-Display MX-121ICE-L02-H Landscape 30pin LVDS 1000 nits IPS 88/88/88/88 -20~70 °C 50K Hr. 278.00*184.00*10.00 261.12*163.20
12.1" 1280x800 12.1 inch 1280x800 Industrial LVDS LCD Module MX-B121FL20-IS81K Landscape 20pin LVDS 1000 nits IPS 85/85/85/85 -20~70 °C 50K Hr. 277.70*180.60*8.70 261.12*163.20
15.0" 1024x768 15-Zoll-Industrie-LCD-Modul mit hoher Helligkeit MX-B150X0M-N101K Landscape 20pin LVDS 1000 nits IPS 89/89/89/89 -20~70 °C 50K Hr. 326.50*253.50*9.70 304.13*228.10
15.6" 1920x1200 15,6-Zoll-Industrie-LCD-Bildschirm MX-H156FL40-IH01 Landscape 40pin LVDS 250 nits IPS 89/89/89/89 0~50 °C 15K Hr. 351.86*206.33*6.31 344.16*193.60
17" 1280x1024 17,0-Zoll-Industrie-LCD-Display MX-B170E0M-N10 Landscape 30pin LVDS 250 nits IPS 89/89/89/89 0~50 ℃ 30K Hr. 358.50*296.50*7.70 337.92*270.34
19.0" 1280x1024 19,0-Zoll-Industrie-LCD-Modul MX190E0M-N11 Landscape 30pin LVDS 250 nits IPS 89/89/89/89 0~50 ℃ 30K Hr. 396.00*324.00*9.90 374.78*299.83
19.0" 1280x1024 19-Zoll-Industrie-LCD-Display mit AG-Glas-Abdecklinse G190ETN01.4-G1KD Landscape 30pin LVDS 1000 nits TN 80/80/85/85 -30~85 °C 50K Hr. 396.00*324.00*12.88 376.32*301.06
21.5" 1920x1080 21,5-Zoll-Industrie-LCD-Panel MX-215FL30BFH-N07 Landscape 30pin LVDS 1000 nits IPS 89/89/89/89 -20~85 ℃ 30K Hr. 495.60*292.20*10.70 476.64*268.11
27" 1920x1080 27-Zoll-Industrie-LCD-Panel MV270FHM-N60 Landscape 30pin LVDS 250 nits IPS 89/89/89/89 0~50 ℃ 30K Hr. 611.50*355.80*13.20 597.89*336.31
32" 1920x1080 32-Zoll-Industrie-LCD-Modul MX320CD05-G1KD Landscape 51pin LVDS 1000 nits IPS 89/89/89/89 -20~80 °C 50K Hr. 730.40x425.00x18.50 698.40x392.85
