10.1 Inch High Brightness IPS TFT LCD Ideal for Outdoor and Marine Applications

Time:2025-05-23 Views:36

10.1 inch LCD screen for fish finder

MAXEN introduces three new 10.1 inch IPS TFT LCD screens in the MX-101FL40BF Series: MX-101FL40BFS-N69MX-101FL40BFH-N71 and MX-101FL40BFH-C73. All of these three TFT LCD models feature a 1280×800 resolution, LVDS interface, and IPS full viewing angles, making them suitable for a variety of industrial and outdoor applications.



The key difference lies in brightness:

  • ☆ MX-101FL40BFS-N69: 400 cd/m² (typical), without touch screen.
  • ☆ MX-101FL40BFH-N71: 1000 cd/m² (typical), without touch screen.
  • ☆ MX-101FL40BFH-C73: 1000 cd/m² (typical), equipped with a PCAP touch panel that supports multi-touch and waterproof operation.



  Model NO.   MX-101FL40BFS-N69   MX-101FL40BFH-N71   MX-101FL40BFH-C73
  Image 10.1 inch tft lcd display-1000nits 10.1 inch LCD Touch Display
  Size   10.1”   10.1”   10.1”
  Resolution   1280*800   1280*800   1280*800
  Module Size   228.20x148.95x2.60 mm   227.56x149.33x5.00 mm   251.50x165.50x7.40 mm
  Active Area   216.96x135.60 mm   216.96x135.60 mm   216.96x135.60 mm
  Viewing Angle   80/80/80/80(IPS)   80/80/80/80(IPS)   80/80/80/80(IPS)
  TFT Interface   LVDS   LVDS   LVDS
  Brightness   400 cd/m²   1000 cd/m²   1000 cd/m²
  Operating Temperature   -10~50℃   -20~70℃   -20~70℃
  Storage Temperature   -20~60℃   -30~80℃   -30~80℃
  PCAP Touch Screen   Without   Without   With PCAP
  PCAP IC   --   --   HY4635
  PCAP Interface   --   --   I2C/USB


One key application is fish finders, where high brightness and waterproof multi-touch functionality are essential. Usually fish finders are used by anglers and marine operators to detect underwater objects and terrain. A responsive, sunlight-readable display ensures visibility and control on open water, even in poor lighting conditions.



Other ideal applications include:

  • ☆ Outdoor POS terminals
  • ☆ EV charging stations
  • ☆ Marine control systems
  • ☆ Industrial equipment



Whether under direct sunlight or in harsh weather, Maxen’s new 10.1” displays deliver clarity and durability where it matters most.
